D-Link DWL-8600AP User Manual

Viewing Multicast Forwarding Database Information
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 242
D-Link UWS User Manual
MFDB Statistics
Use the multicast forwarding database Stats page to view statistical information about the MFDB table.
To access the Stats page, click LAN > Monitoring > Multicast Forwarding Database > Statistics in the
navigation tree.
Figure 147: Multicast Forwarding Database Statistics
• Click Refresh to update the information on the screen with the most current data.
Table 131: Multicast Forwarding Database Statistics Fields
Field Description
Max MFDB Entries Shows the maximum number of entries that the Multicast Forwarding
Database table can hold.
Most MFDB Entries Since Last
Reset
The largest number of entries that have been present in the Multicast
Forwarding Database table since the system was last reset. This value is also
known as the MFDB high-water mark.
Current Entries Shows the current number of entries in the Multicast Forwarding Database
table.

D-Link DWL-8600AP Specifications

General

Modulation	DBPSK, DQPSK, DSSS, OFDM
Cabling technology	10/100/1000Base-T(X)
Maximum data transfer rate	300 Mbit/s
Frequency range	2400 - 2497 MHz
Wireless technology	802.11a/b/g/n
Compliance industry standards	IEEE 802.11a, 802.11b, 802.11g, 802.11n, IEEE 802.3, 802.3u, IEEE 802.11d, IEEE 802.11h, IEEE 802.3x, IEEE 802.3af
Antenna connector type	SMA
DC-in jack	Yes
Ethernet LAN (RJ-45) ports	1
AC input voltage	48 V
Power supply type	DC
Power consumption (typical)	12 W
Storage temperature (T-T)	-20 - 65 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Certification	-FCC Class B, -CE, -C-Tick, -VCCI, -TELEC, -Wi-Fi, - ICES-003, -EN60601-1-2, -NCC, -CSA.

Weight and Dimensions

Weight	1020 g
Dimensions (WxDxH)	190.5 x 198.8 x 36.8 mm
