D-Link DWL-8600AP User Manual

Locating WLAN Devices
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 651
D-Link UWS User Manual
Figure 408: Building
The following table shows the fields available on the Building page.
Command Buttons
The page includes the following buttons:
• Delete— Deletes the selected building from the database.
• Delete All—Deletes all buildings configured in the database.
• Refresh—Updates the page with the latest information.
Table 374: Building
Field Description
Building Number Unique number from 1–8 that identifies a building within the wireless
system.
Building Description A description for the building, such as an address or function. The
name can be up to 64 characters. The default name is Building-n,
where n is the building number.
Total Floor Count Number of floors configured for the building.
Total AP Count Number of APs in the building with an administratively-configured
physical location.

D-Link DWL-8600AP Specifications

General

Modulation	DBPSK, DQPSK, DSSS, OFDM
Cabling technology	10/100/1000Base-T(X)
Maximum data transfer rate	300 Mbit/s
Frequency range	2400 - 2497 MHz
Wireless technology	802.11a/b/g/n
Compliance industry standards	IEEE 802.11a, 802.11b, 802.11g, 802.11n, IEEE 802.3, 802.3u, IEEE 802.11d, IEEE 802.11h, IEEE 802.3x, IEEE 802.3af
Antenna connector type	SMA
DC-in jack	Yes
Ethernet LAN (RJ-45) ports	1
AC input voltage	48 V
Power supply type	DC
Power consumption (typical)	12 W
Storage temperature (T-T)	-20 - 65 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Certification	-FCC Class B, -CE, -C-Tick, -VCCI, -TELEC, -Wi-Fi, - ICES-003, -EN60601-1-2, -NCC, -CSA.

Weight and Dimensions

Weight	1020 g
Dimensions (WxDxH)	190.5 x 198.8 x 36.8 mm
