D-Link DWL-8600AP User Manual

Secure Shell (SSH) Configuration
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 382
D-Link UWS User Manual
Secure Shell (SSH) Configuration
If you use the command-line interface (CLI) to manage the switch from a remote system, you can use Secure
Shell (SSH) to establish a secure connection. SSH uses public-key cryptography to authenticate the remote
computer.
Secure Shell Configuration
Use the Secure Shell Configuration page to configure the settings for secure command-line based
communication between the management station and the switch.
To display the Secure Shell Configuration page, click LAN > Security > Secure Shell > SSH Configuration in the
navigation menu.
Figure 258: Secure Shell Configuration
Table 222: Secure Shell Configuration Fields
Field Description
Admin Mode This select field is used to Enable or Disable the administrative mode of SSH.
The currently configured value is shown when the web page is displayed. The
default value is Disable.
SSH Version 1 This select field is used to Enable or Disable Protocol Level 1 for SSH. The
currently configured value is shown when the web page is displayed. The
default value is Enable.
SSH Version 2 This select field is used to Enable or Disable Protocol Level 2 for SSH. The
currently configured value is shown when the web page is displayed. The
default value is Enable.
SSH Connections in Use Displays the number of SSH connections currently in use in the system.
Maximum Number of SSH
Sessions Allowed
This select field is used to configure the maximum number of inbound SSH
sessions allowed on the switch. The currently configured value is shown when
the web page is displayed. The range of acceptable values for this field is (0-5).

D-Link DWL-8600AP Specifications

General

Modulation	DBPSK, DQPSK, DSSS, OFDM
Cabling technology	10/100/1000Base-T(X)
Maximum data transfer rate	300 Mbit/s
Frequency range	2400 - 2497 MHz
Wireless technology	802.11a/b/g/n
Compliance industry standards	IEEE 802.11a, 802.11b, 802.11g, 802.11n, IEEE 802.3, 802.3u, IEEE 802.11d, IEEE 802.11h, IEEE 802.3x, IEEE 802.3af
Antenna connector type	SMA
DC-in jack	Yes
Ethernet LAN (RJ-45) ports	1
AC input voltage	48 V
Power supply type	DC
Power consumption (typical)	12 W
Storage temperature (T-T)	-20 - 65 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Certification	-FCC Class B, -CE, -C-Tick, -VCCI, -TELEC, -Wi-Fi, - ICES-003, -EN60601-1-2, -NCC, -CSA.

Weight and Dimensions

Weight	1020 g
Dimensions (WxDxH)	190.5 x 198.8 x 36.8 mm
