D-Link DWL-8600AP User Manual

RADIUS Settings
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 418
D-Link UWS User Manual
Viewing Named Accounting Server Status
The RADIUS Named Accounting Server Status page shows summary information about the accounting servers
configured on the system.
Figure 288: RADIUS Named Accounting Server Status
Click Refresh to update the page with the most current information.
Table 246: Named Accounting Server Fields
Field Description
RADIUS Accounting Server
Name
Shows the RADIUS accounting server name.
Multiple RADIUS accounting servers can have the same name. In this case,
RADIUS clients can use RADIUS servers with the same name as backups for
each other.
IP Address Shows the IP address of the RADIUS server.
Port Number Identifies the authentication port the server uses to verify the RADIUS server
authentication. The port is a UDP port.
Secret Configured Indicates whether the shared secret for this server has been configured.

D-Link DWL-8600AP Specifications

General

Modulation	DBPSK, DQPSK, DSSS, OFDM
Cabling technology	10/100/1000Base-T(X)
Maximum data transfer rate	300 Mbit/s
Frequency range	2400 - 2497 MHz
Wireless technology	802.11a/b/g/n
Compliance industry standards	IEEE 802.11a, 802.11b, 802.11g, 802.11n, IEEE 802.3, 802.3u, IEEE 802.11d, IEEE 802.11h, IEEE 802.3x, IEEE 802.3af
Antenna connector type	SMA
DC-in jack	Yes
Ethernet LAN (RJ-45) ports	1
AC input voltage	48 V
Power supply type	DC
Power consumption (typical)	12 W
Storage temperature (T-T)	-20 - 65 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Certification	-FCC Class B, -CE, -C-Tick, -VCCI, -TELEC, -Wi-Fi, - ICES-003, -EN60601-1-2, -NCC, -CSA.

Weight and Dimensions

Weight	1020 g
Dimensions (WxDxH)	190.5 x 198.8 x 36.8 mm
