Configuring Differentiated Services
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 346
D-Link UWS User Manual
Policy Configuration
Use the Policy Configuration page to associate a collection of classes with one or more policy statements.
To display the page, click LAN > QoS > Differentiated Services > Policy Configuration in the navigation menu.
The fields available on the Policy Configuration page depend on whether you create a new class or configure
a class that has already been created.
Figure 228 shows the Policy Configuration page when the Policy Selector option is Create.
Figure 228: Policy Configuration
Figure 229 shows the Policy Configuration page when the Policy Selector option shows a configured policy that
has a member class. To configure a member class, see “Class Configuration” on page 343.
Figure 229: Policy Configuration
Table 206: Policy Configuration Fields
Field Description
Policy Selector To create a new policy, select Create from the menu; another page appears to
facilitate creation of a new policy. To change a policy name or to modify the
class list members, select the policy name from the menu. To delete an
existing policy select it from the menu, and then click Delete.
Policy Name If you select Create from the Policy Selector menu, enter a name to associate
with the class(es). The name is a case-sensitive alphanumeric string from 1 to
31 characters uniquely identifying a policy. To modify the name of an existing
policy, select it from the Policy Selector menu and enter a new name in the
Policy Name field, and then click Rename.
