D-Link DWL-8600AP User Manual

Basic Setup
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 543
D-Link UWS User Manual
Command Buttons
The page includes the following buttons:
• Refresh—Updates the page with the latest information.
• Submit—Updates the switch with the values you enter. To retain the new values across a power cycle,
you must perform a save on the WLAN switch (not the AP). To perform a save, click Tool > Save Changes.
• Next—Navigates to the next page in the Basic Setup configuration. Any changes you made to the current
page are saved before the next page is displayed. To retain the new values across a power cycle, you must
perform a save on the WLAN switch (not the AP). To perform a save, click Tool > Save Changes.
Regenerate X.509
Certificate Status
Status of the request to generate an X.509 certificate. To initiate X.509 certificate
generation, go to the Advanced Configuration > Switch Provisioning page.
The field has one of the following values:
• Certificate Generation is not in progress
• Start Certificate Generation
• Certificate Generation is in progress.
Manage AP with
Previous Release Code
For networks that include DWL-8600APs running a software version earlier than
v2.0, you must select this option to allow the switch to discover the APs and upgrade
the AP software to the current release.
Note: After the APs have been discovered, upgraded, and become managed by the
switch, clear this option.
Table 324: Basic Wireless Global Configuration (Cont.)
Field Description

D-Link DWL-8600AP Specifications

General

Modulation	DBPSK, DQPSK, DSSS, OFDM
Cabling technology	10/100/1000Base-T(X)
Maximum data transfer rate	300 Mbit/s
Frequency range	2400 - 2497 MHz
Wireless technology	802.11a/b/g/n
Compliance industry standards	IEEE 802.11a, 802.11b, 802.11g, 802.11n, IEEE 802.3, 802.3u, IEEE 802.11d, IEEE 802.11h, IEEE 802.3x, IEEE 802.3af
Antenna connector type	SMA
DC-in jack	Yes
Ethernet LAN (RJ-45) ports	1
AC input voltage	48 V
Power supply type	DC
Power consumption (typical)	12 W
Storage temperature (T-T)	-20 - 65 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Certification	-FCC Class B, -CE, -C-Tick, -VCCI, -TELEC, -Wi-Fi, - ICES-003, -EN60601-1-2, -NCC, -CSA.

Weight and Dimensions

Weight	1020 g
Dimensions (WxDxH)	190.5 x 198.8 x 36.8 mm
