6-10

FUEL SYSTEM

PILOT SCREW

THROTTLE STOP SCREW

PILOT SCREW

THROTTLE STOP SCREW

ACCELERATION

⑥ When idling, check to see if the rotation is smoothly

and to return is nomal.

● Install the center cover.

If the engine cannot be adjusted by turning the

pilot screw within a ¼ turn, check for other

engine problems.

CAUTION

EMISSION ANALYZER IS NOT EXIST

① Turn the pilot screw clockwise until it seats lightly,

then back it out to the specification given(1½).

② Warm up the engine to operating temperature (60℃).

③ Adjust the idle speed with the throttle stop screw.

IDLE SPEED : 1,700

±±

100RPM

Before adjustment the pilot screw, check the

following items.

- Fuel system electrical system for troubling.

- Do not force the pilot screw against its seat ;

The seat will be damaged.

- Spark plug for cleaning and gap adjusting.

- Valve clearance for adjusting.

NOTE

④ When idling, check to see if the rotation is smoothly

and to return is normal.

⑤ Turn the throttle stop screw until the 1,000RPM, and

check the stopping of engine.

If the engine is stop, adjust the pilot screw with a ⅛,

and repeat step ④ and ⑤.
