7-1
ENGINE REMOVAL/INSTALLATION
7. ENGINE REMOVAL/INSTALLATION
SERVICE INFORMATION
·····
7-1
ENGINE REMOVAL/INSTALLATION
·
7-2
SERVICE INFORMATION
GENERAL SAFETY
NOTE
•Use a jack to remove or install the engine. Support the motorcycle with a jack firmly, taking precautions not to
damage the frame, engine, cable or harness.
•Attach tape to the frame to protect it during the engine removal or installation.
● The following works can be carried out without removing the engine from the vehicle body.
-TRANSMISSION (⇨SECTION 12)
-STARTING CLUTCH (⇨SECTION 9)
-OIL PUMP (⇨SECTION 4)
-A.C. GENERATOR (⇨SECTION 9)
-START MOTOR (⇨SECTION 18)
-CONTINUOUSLY VARIABLE TRANSMISSION (⇨SECTION 8)
-CYLINDER HEAD/ CYLINDER/ PISTON (⇨SECTION 10,11)
-EX. MUFFLER (⇨SECTION 3)
-CARBURETOR (⇨SECTION 6)
-REAR SWING ARM (⇨SECTION 14)
● Items to be worked after removing engine.
-CRANKSHAFT, CRANKSHAFT BEARING, CRANK CASE BEARING
● Engine oil capacity : 1.1ℓ - When disassembled.
TORQUE VALUES :
ENGINE HANGER BOLT (FRONT) : 2.7
㎏
f
·
m
(REAR) : 3.5
㎏
f
·
m
7
