DAELIM B-BONE Service Manual

3-4
EXTERNAL PARTS
●Remove the speedometer cable and
speedometer.
●Loosen the 6 tapping screw securing the front
side cover.
●Loosen the 3 special screw securing the front
cover and remove the front cover.
●Install in the reverse order of removal
FRONT FENDER
REMOVAL/ASSEMBLY
●Loosen the 4 special screws (R/L).
●Remove the wire grommet.
●Remove the front fender.
●Install in the reverse order of removal.
FRONT UNDER COVER
REMOVAL/ASSEMBLY
●Loosen the 4 tapping screws (R/L) securing
the front of the floor panel.
●Loosen the 2 flange bolts securing the front
under cover.
●Loosen the 4 washer screws (R/L) securing
front of the floor side cover.
