DAELIM B-BONE Service Manual

1-3
SERVICE INFORMATION
※“( )”MARKED CONTENTS APPLY TO EURO2 ONLY
ITEM SPECIFICATIONS
CV type ( vacuum ) / '“24.2 mm
CVK
Auto-bystarter
# 95
2
½
17 mm
1.700±100 rpm
Automatic Transmission
3.000
2.786
ECU (C.D.I)
Closed type (MF) 12V 10AH
CR8EH -9 (NGK)
0.8 - 0.9 mm
15A, 30A (15A)
Starter motor
12V 55W / 12V 55W
12V 5W
12V 10W
×4
12V 21 / 5W
LED
LED
LED
12V 5W
TYPE / VENTURI BORE
MODEL MARK
CHOKE TYPE
MAIN JET
PILOT SCREW INITIAL SETTING
FLOAT LEVEL
IDLE SPEED
CLUTCH TYPE
PRIMARY REDUCTION
SECONDARY REDUCTION
IGNITION SYSTEM
BATTERY TYPE / CAPACITY
SPARK PLUG
SPARK PLUG GAP
FUSE CAPACITY
STARTING SYSTEM
HEADLIGHT ( HIGH / LOW )
POSITION LIGHT
WINKER LIGHTS ( FR / RR )
TAIL / STOP LIGHT
HIGH-BEAM PILOT
WINKER PILOT
METER LIGHTS
LICENSE LAMP
(CARBURETOR)
DRIVE TRAIN
ELECTRICAL
SYSTEM

DAELIM B-BONE Specifications

General

Brand	DAELIM
Model	B-BONE
Category	Scooter
Language	English
