REAR WHEEL / SUSPENSION / REAR SWING ARM
SERVICE INFORMATION
● Use the specified tire lever and rim protector to remove or assemble tires to protect the rim from being damage.
SPECIFICATIONS
TORQUE VALUES :
REAR CUSHION UPPER BOLT 3.5~4.5㎏f·m
REAR CUSHION UNDER BOLT 3.5~4.5㎏f·m
REAR CUSHION ROD LOCK NUT 3.0~4.5㎏f·m
REAR AXLE NUT 6.0~8.0㎏f·m
14
SERVICE INFORMATION
···
14-1
TROUBLESHOOTING
····
14-2
REAR WHEEL
··
········
14-3
REAR CUSHION
·····
··
14-5
REAR SWING ARM
·····
··
14-6
ITEM STANDARD VALUE SERVICE LIMIT
!
CAUTION
REAR WHEEL RIM RUN OUT
REAR CUSHION SPRING FREE LENGTH
-
219 mm
2.0 mm
215 mm
REAR WHEEL/SUSPENSION/REAR SWING ARM
