LH. CRANKCASE COVER

DISASSEMBLY

● Remove the air cleaner and flange bolt securing B stay.

● Remove the flange bolts securing LH. crankcase.

● Remove the LH. crankcase cover.

● Remove the gasket and dowel pin.

INSTALLATION

● Install the new gasket and dowel pin after removing the

gasket of the crankcase surface.

● Install the LH. crankcase cover.

● Install the air cleaner and B stay and tighten the flange

bolt.

8-2

LH.CRANK CASE COVER/CONTINUOUSLY VARIABLE TRANSMISSION

LH. COVER GASKET

DRIVE FACE

DRIVEN PULLEY

AIR CLEANER

LH. CRANK CASE COVER

Tighten the bolts diagonally with specified

tightening torque.

Be sure to replace a new gasket and dowel pin.

NOTE

B-STAY
