13. FRONT WHEEL/FRONT FORK/STEERING
SERVICE INFORMATION
GENERAL SAFETY
● Use special tire levers and rim protectors to remove or assemble tires to protect the rim from being damaged.
● Place a jack underneath the engine to support the 2-wheeled vehicle.
SPECIFICATIONS
TORQUE VALUES
STEERING STEM LOCK NUT 7.84~11.76 ㎏f·m
STEERING TOP CONE RACE 0.49~1.27 ㎏f·m
FRONT CUSHION BOLT 1.98~2.45 ㎏f·m
FRONT AXLE NUT 4.41~4.9 ㎏f·m
BRAKE CALIPER BOLT 2.45~3.43 ㎏f·m
13
SERVICE INFORMATION
····
13-1
TROUBLESHOOTING
·····
13-2
STEERING HANDLE
·····
13-3
FRONT WHEEL
·······
13-4
FRONT WHEEL BEARING
···
13-5
SPEEDOMETER GEAR
····
13-6
FRONT WHEEL INSTALLATION
·
13-7
FRONT FORK
········
13-7
STEERING STEM
······
13-12
RADICAL
AXIAL
ITEM
AXLE SHAFIT DEFLECTION
FRONT CUSHION SPRING FREE LENGTH
STANDARD VALUE (mm)
-
-
-
266.3
SERVICE LIMIT (mm)
0.2
2.0
2.0
FRONT WHEEL RIM DEFLECTION
!
CAUTION
FRONT WHEEL/FRONT FORK/STEERING
