DAELIM B-BONE

5-39
EMS(Engine Management System)
● Remove the fuel hose.
● Remove the fuel pump coupler.
● Loosen the 4 fuel pump setting place screws.
REMOVE
● Fuel pump is located inside the fuel tank.
● Remove the fuel filler cap.
● Remove the floor panel.
!
CAUTION
△
16. FUEL PUMP
● Make sure that the key is off before assembly.
● Remove the fuel pump.
