18-1
18. STARTER SYSTEM
SERVICE INFORMATION
GENERAL SAFETY
·Always turn the ignition switch OFF before servicing the starter motor. The moter could suddenly start, causing
serious injury.
● The starter motor can be maintained without removing the engine from the vehicle.
● A weak battery may be unable to turn the starter motor quickly enough, or, supply adequate ignition current.
● The starter motor may be damaged if current is allowed to flow to it when the engine cannot turn over.
● The engine may not be turned over if the stop switch is faulty.
SPECIFICATION
18
SERVICE INFORMATION
····
18-1
TROUBLESHOOTING
·····
18-2
STARTER MOTOR
······
18-3
STARTER MAGNETIC SWITCH
·
18-6
ITEM
STARTER MOTOR BRUSH LENGTH
STANDARD VALUE
10.2 mm
SERVICE LIMIT
5 mm
TOOLS
DIGITAL TESTER
VERNIER CALIPER
!
WARNING
△
STARTER SYSTEM
