18-0
STARTER SYSTEM
M
CABLE
CABLE
STARTER
RELAY
STARTER
MOTOR
BATTERY
(12V 10AH
FUSE
Y/R
STARTER
SWITCH
REAR
STOP
SWITCH
G/Y
STOP LAMP
G/Y
FRONT
STOP
SWITCH
B
MAIN
SWITCH
G
STARTER SYSTEM
