User’s Manual
54
Submenu Setting
TIMER1/TIMER2/
TIMER3/TIMER4
Follows the setting of timers (00 to 16).
The outputs can also be associated with a maximum of 4 (
Start
/
Stop
)
timers which can limit the outputs operation to specific time periods
during the week.
Press and or directly press the value + to alter the timer
to be set. After making the selection, press to move to the next
field, and after setting the fourth timer, press to move to the
Polar
screen.
POLAR
The choice of the output polarity determines the at rest status of the
output itself. In practice, the output can be placed in
HIGH
or
LOW
electrical status (high status gets more security).
●
DIRECT
●
REVERSE
If you press to confirm the option, you will exit and the output
will immediately take on the selected polarity.
Generic Outputs
The generic outputs are only used by timers (up to 4 timers).
In practice, the outputs are activated following the time slots on the
Timers
and the activation
duration can be programmed as
TOGGLE
(000.00=TOGGLE) or
PULSE
(timed).
Table 7-9 Generic outputs programming
Item Setting
GEN ACT DUR
●
Set the activation time of the output (minutes/seconds).
●
Setting it to 000.00 makes it
Toggle
.
GEN ACT DLY Set an eventual delay time before output starts (minutes/seconds).
TRIGGER
This parameter is shown only if the delay is programmed in
impulse mode.
●
SINGLE
: During its impulse activation, a further command
does not restart the impulse time. In this case, the
LINK
can
reactivate only after the entire impulse duration has elapsed.
●
CONTINUOUS
: During its impulse activation, when another
command is received, the impulse time restarts from the
beginning time.
●
In practice,
TRIGGER
auto-regenerates at each new impulse
until it comes to the end of the set time.
TIMER1/TIMER2/
TIMER3/TIMER4
Follows the setting of timers (00 to 16).
The outputs can also be associated with a maximum of 4
(
Start
/
Stop
) timers which can limit the outputs operation to
specific time periods during the week.
Press and or directly press the value + to alter the
timer to be set. After making the selection, press to move to
the next field, and after setting the fourth timer, press to move
to the
Polar
screen.
