User’s Manual
53
Submenu Setting
MODALITY
The zone outputs can be programmed to follow the association condition
for
AND
and
OR
mode.
If only one zone has been assigned, this parameter has
NO
value. If 2 to 4
zones have been assigned, the behavior of the output must be defined
for the presentation of the event by multiple zones.
●
OR
: The output activates when the event occurs in one of the
assigned areas and deactivates when there is a reset from all the
assigned areas.
●
AND
: The output activates when the event occurs in all of the
assigned areas and deactivates when there is a reset from at least one
of the areas.
If only one area has been assigned, this parameter has no value.
POLAR
The choice of the output polarity determines the at rest status of the
output itself. In practice, the output can be placed in
HIHG
or
LOW
electrical status (high status gets more security).
●
DIRECT
●
REVERSE
If you press to confirm the option, you will exit and the output
will immediately take on the selected polarity.
Link Outputs
Link outputs can be commanded by the user or by association with zone inputs. In practice, outputs
are activated following the status of specific (wired or wireless) zones or through a direct manual
command and can be programmed as
Toggle
or
Pulse
.
The outputs can also be associated with a maximum of 4 (
Start
/
Stop
) timers which can limit the
outputs operations to specific time periods during the week.
Table 7-8 Link outputs programming
Submenu Setting
LINK ACT DUR Set the activation time of the output (minutes/seconds).
LINK ACT DLY Set an eventual delay time before output starts (minutes/seconds).
TRIGGER
This parameter is shown only if the delay is programmed in impulse
mode.
●
SINGLE
: During its impulse activation, a further command does not
restart the impulse time. In this case, the link can reactivate only
after the entire impulse duration has elapsed.
●
CONTINUOUS
: During its impulse activation, when another
command is received, the impulse time restarts from the beginning
time.
In practice,
TRIGGER
auto-regenerates at each new impulse until it
comes to the end of the set time.
