User’s Manual
52
Submenu Setting
AREAS
Select the areas (1 to 8) that you want to assign the outputs to. The areas can be
assigned in individual or combined mode. In the case of multiple areas, the output
is connected to them in
OR
or
AND
mode that is defined on the next screen.
To assign or remove areas from the keypad, press the corresponding key (1 to 8)
and then press . The number of the assigned area appears on the
programming line to confirm that the selection was successful. The number of the
assigned area disappears from the programming line to confirm that the selection
was cancelled.
MODALITY
The area output can be programmed to follow the areas condition for
AND
or
OR
mode.
If only one area has been assigned, this parameter has
NO
value. If 2 to 8 areas
have been assigned, the behavior of the output must be defined for the
presentation of the
TYPE
event in multiple areas.
●
OR
: The output activates when the event occurs in one of the assigned areas
and deactivates when there is a reset from all the assigned areas.
●
AND
: The output activates when the event occurs in all of the assigned areas
and deactivates when there is a reset from at least one of the areas.
If only one area has been assigned, this parameter has no value.
POLAR
Select the output polarity. The choice of the output polarity determines the at rest
status of the output itself. In practice, the output can be placed in
HIGH
or
LOW
electrical status (high status gets more security)
●
DIRECT
●
REVERSE
If you press to confirm the option, you will exit and the output will
immediately take on the selected polarity.
Zones Outputs
Table 7-7 Zones outputs programming
Submenu Setting
TYPE
●
ZONE FOLLOW
: Follows the direct status of the zone (open and
closed).
●
ZONE ALARM
: Follows the zone alarm status until reset.
●
ZONE BYPASS
: Follows the bypassed zone status.
●
ZONE TAMPER
: Follows the tamper status.
ZONE1/ZONE2/
ZONE3/ZONE4
You can associate the output with up to a maximum of 4 different zones
(wire or radio zones)
