41
Table 3-11 Image playback
No. Function Description
1
Control button
for playing
pictures
Includes the following two types:
When this icon displays, the picture playback is paused or
not started. Click this icon to start picture playback.
When this icon displays, the picture playback is ongoing.
Click this icon to stop picture playback.
The two states above can be switched.
2
Snapshot type
selection
There are three types including General, Event and Alarm, and you
can select one of them according to actual needs.
3 Playback file list You can select file type and snapshot data.
3.3.2.2 Picture Playback
You can check and play a snapshot image based on your own needs.
Select a snapshot type in the selection bar of snapshot type. See Figure 3-37. Step 1
Snapshot type selection Figure 3-37
Select jpg in File Type. See Figure 3-38. Step 2
File type contains dav and jpg. "Dav" represents video playback and “jpg” represents image
playback.
Configuring playback files Figure 3-38
Those dates with blue color indicate there are snapshot images in those days. Select a date Step 3
with snapshot images inside.
Play images. Step 4
Click in the play control bar and the system plays the snapshots you have selected
(in time order).
Click which represents the file list, pictures which you have selected would be
displayed. Double-click a file in the list. See Figure 3-39. The file is displayed.
For detailed operations, see Table 3-12.
