92
Table 4-25 Abandoned object parameters
Parameter Description
Period
Define a period during which the alarm settings are active.
1. Click Setting, and the period setting interface is displayed.
2. Configure period.
Method 1: Hold down and drag the left mouse button to select
working period you need.
Method 2: Select Setting > Event > Video Detection and click
Setting on the right side of Period. An interface is displayed. In this
interface, there are seven Setting
s altogether each of which
corresponds to a day in a week. Select a Setting you want and
there are six periods (period1-period6) below for you to pick up.
3. Click Save of working period.
Duration
The shortest time from placing an object in the detection area to an alarm is
triggered.
Alarm Track
Enable this function and when tripwire is triggered, the Camera will use
thermal lens or visual lens to track the object.
Track Time Time for the lens to track the object.
To set linked measures such as Audio Linkage and White Light when the rule box detects an Step 4
object, see "4.4.10 Configure Linked Measures."
Click Save. Step 5
4.4.2.2.4 Missing Object
When an object is taken away from the detection area and the absent time of the object is longer
than the defined one, an alarm will be triggered and linked activities will be executed.
Procedure
Select Setting > Smart Thermal > IVS. Step 1
The Rule Config interface is displayed.
Select a preset in Preset bar. Step 2
The camera turns to the position.
Set rules about those missing objects. Step 3
1) Click to add a rule. In the Rule Type column list, select Abandoned Object. In the
Name column, double-click a name, Rule4, for example, to define it. See Figure 4-47.
