Daihen OTC Almega AX Series User Manual

1.4 Welding mode lists
1-36
Welding mode
Welding
process
Gas
Wire
material
Wire
diameter
Travel
speed
Welding mode description
Notes
Number of welding
characteristic data
in AX21/FD11
DC MIG※2 SUS 1.2
Extended
cable
400A Mig_4 DC φ1.2 SuS (Low*) $WTBD3579
〃 MIG※1 Hard Alm 1.2 〃 400A Mig_3 DC φ1.2 Hard Al (Low*) $WTBD3581
〃 〃 〃 1.6 〃 400A Mig_3 DC φ1.6 Hard Al (Low*) $WTBD3582
〃 〃 Soft Alm 1.2 〃 400A Mig_3 DC φ1.2 Soft Al (Low*) $WTBD3583
〃 〃 〃 1.6 〃 400A Mig_3 DC φ1.6 Soft Al (Low*) $WTBD3584
DC
wave
pulse
MAG
Mild Steel
Solid
0.9 High 400A Mag DC-Wave φ0.9 (High) $WTBD3585
〃 〃 〃 1.0 〃 400A Mag DC-Wave φ1.0 (High) $WTBD3586
〃 〃 〃 1.2 〃 400A Mag DC-Wave φ1.2 (High) $WTBD3587
〃 MIG※2 SUS 0.9 〃 400A Mig_4 DC-Wave φ0.9 SuS (High) $WTBD3588
〃 〃 〃 1.2 〃 400A Mig_4 DC-Wave φ1.2 SuS (High) $WTBD3590
〃 MIG※1 Hard Alm 1.2 〃 400A Mig_3 DC-Wave φ1.2 Hard Al (High) $WTBD3591
〃 〃 〃 1.6 〃 400A Mig_3 DC-Wave φ1.6 Hard Al (High) $WTBD3592
〃 〃 Soft Alm 1.2 〃 400A Mig_3 DC-Wave φ1.2 Soft Al (High) $WTBD3593
〃 〃 〃 1.6 〃 400A Mig_3 DC-Wave φ1.6 Soft Al (High) $WTBD3594
〃 MAG
Mild Steel
Solid
0.9 Standard 400A Mag DC-Wave φ0.9 (Low) $WTBD3595
〃 〃 〃 1.0 〃 400A Mag DC-Wave φ1.0 (Low) $WTBD3596
〃 〃 〃 1.2 〃 400A Mag DC-Wave φ1.2 (Low) $WTBD3597
〃 MIG※2 SUS 0.9 〃 400A Mig_4 DC-Wave φ0.9 SuS (Low) $WTBD3598
〃 〃 〃 1.2 〃 400A Mig_4 DC-Wave φ1.2 SuS (Low) $WTBD3600
〃 MIG※1 Hard Alm 1.2 〃 400A Mig_3 DC-Wave φ1.2 Hard Al (Low) $WTBD3601
〃 〃 〃 1.6 〃 400A Mig_3 DC-Wave φ1.6 Hard Al (Low) $WTBD3602
〃 〃 Soft Alm 1.2 〃 400A Mig_3 DC-Wave φ1.2 Soft Al (Low) $WTBD3603
〃 〃 〃 1.6 〃 400A Mig_3 DC-Wave φ1.6 Soft Al (Low) $WTBD3604
DC 〃 Cu-Si 0.8 〃 400A Mig_3 DC φ0.8 Cu-Si (Low) $WTBD3605
〃 〃 〃 0.9 〃 400A Mig_3 DC φ0.9 Cu-Si (Low) $WTBD3606
〃 〃 〃 1.2 〃 400A Mig_3 DC φ1.2 Cu-Si (Low) $WTBD3608
〃 〃 Cu-Al 0.8 〃 400A Mig_3 DC φ0.8 Cu-Al (Low) $WTBD3609
〃 〃 〃 0.9 〃 400A Mig_3 DC φ0.9 Cu-Al (Low) $WTBD3610
〃 〃 〃 1.2 〃 400A Mig_3 DC φ1.2 Cu-Al (Low) $WTBD3612
DC
pulse
〃 Cu-Si 0.8 〃 400A Mig_3 DC-Pulse φ0.8 Cu-Si (Low) $WTBD3617
〃 〃 〃 0.9 〃 400A Mig_3 DC-Pulse φ0.9 Cu-Si (Low) $WTBD3618
〃 〃 〃 1.2 〃 400A Mig_3 DC-Pulse φ1.2 Cu-Si (Low) $WTBD3620
〃 〃 Cu-Al 0.8 〃 400A Mig_3 DC-Pulse φ0.8 Cu-Al (Low) $WTBD3621
〃 〃 〃 0.9 〃 400A Mig_3 DC-Pulse φ0.9 Cu-Al (Low) $WTBD3622
〃 〃 〃 1.2 〃 400A Mig_3 DC-Pulse φ1.2 Cu-Al (Low) $WTBD3624
DC 〃 Cu-Si 0.8
Extended
cable
400A Mig_3 DC φ0.8 Cu-Si (Low*) $WTBD3635
DC
pulse
MAG
Mild Steel
Solid
0.8 High 400A Mag DC-Pulse φ0.8 (High) $WTBD3637
〃 MIG※2 SUS
0.8
〃 400A Mig_4 DC-Pulse φ0.8 SuS (High) $WTBD3652
〃 〃 Ferrite
0.8
〃 400A Mig_4 DC-Pulse φ0.8 Ferrite (High) $WTBD3653
〃 〃 〃 0.9 〃 400A Mig_4 DC-Pulse φ0.9 Ferrite (High) $WTBD3654
〃 〃 〃 1.2 〃 400A Mig_4 DC-Pulse φ1.2 Ferrite (High) $WTBD3656
〃 MIG※1 Cu-Si 0.8 High 400A Mig_3 DC-Pulse φ0.8 Cu-Si (High) $WTBD3661
〃 〃 〃 0.9 〃 400A Mig_3 DC-Pulse φ0.9 Cu-Si (High) $WTBD3662
〃 〃 〃 1.2 〃 400A Mig_3 DC-Pulse φ1.2 Cu-Si (High) $WTBD3664
〃 〃 Cu-Al 0.8 〃 400A Mig_3 DC-Pulse φ0.8 Cu-Al (High) $WTBD3665
〃 〃 〃 0.9 〃 400A Mig_3 DC-Pulse φ0.9 Cu-Al (High) $WTBD3666
〃 〃 〃 1.2 〃 400A Mig_3 DC-Pulse φ1.2 Cu-Al (High) $WTBD3668
〃 〃 INCONEL 0.9 〃 400A Mig_3 DC-Pulse φ0.9 Inconel (High) $WTBD3669
〃 〃 〃 1.2 〃 400A Mig_3 DC-Pulse φ1.2 Inconel (High) $WTBD3670
DC
wave
pulse
MAG
Mild Steel
Solid
0.8 High 400A Mag DC-Wave φ0.8 (High) $WTBD3673
〃 MIG※2 SUS
0.8
〃 400A Mig_4 DC-Wave φ0.8 SuS (High) $WTBD3686
〃 〃 Ferrite
0.8
〃 400A Mig_4 DC-Wave φ0.8 Ferrite (High) $WTBD3687
〃 〃 〃 0.9 〃 400A Mig_4 DC-Wave φ0.9 Ferrite (High) $WTBD3688
〃 〃 〃 1.2 〃 400A Mig_4 DC-Wave φ1.2 Ferrite (High) $WTBD3690
DC MAG
Mild Steel
Cored
1.2 Standard 400A Mag DC φ1.2 (Cored) (Low) $WTBD3693
