1.4 Welding mode lists
1-37
Welding mode
Welding
process
Gas
Wire
material
Wire
diameter
Travel
speed
Welding mode description
Notes
Number of welding
characteristic data
in AX21/FD11
DC MAG SUS Cored 1.2 Standard 400A Mag DC φ1.2 SuS(Cored) (Low) $WTBD3694
DC
pulse
MIG※2 SUS 0.8 〃 400A Mig_4 DC-Pulse φ0.8 SuS (Low) $WTBD3719
〃 〃 Ferrite 0.8 〃 400A Mig_4 DC-Pulse φ0.8 Ferrite (Low) $WTBD3720
〃 〃 〃 0.9 〃 400A Mig_4 DC-Pulse φ0.9 Ferrite (Low) $WTBD3721
〃 〃 〃 1.2 〃 400A Mig_4 DC-Pulse φ1.2 Ferrite (Low) $WTBD3723
DC 〃 〃 1.0 High 400A Mig_4 DC φ1.0 Ferrite (High) $WTBD3728
〃 〃 〃 1.2 〃 400A Mig_4 DC φ1.2 Ferrite (High) $WTBD3729
〃 〃 〃 1.0 Standard 400A Mig_4 DC φ1.0 Ferrite (Low) $WTBD3730
〃 〃 〃 1.2 〃 400A Mig_4 DC φ1.2 Ferrite (Low) $WTBD3731
〃 MIG※1 Cu-Al 0.8
Extended
cable
400A Mig_3 DC φ0.8 Cu-Al (Low*) $WTBD3732
〃 〃 〃 0.9 〃 400A Mig_3 DC φ0.9 Cu-Al (Low*) $WTBD3733
〃 〃 〃 1.2 〃 400A Mig_3 DC φ1.2 Cu-Al (Low*) $WTBD3735
DC
pulse
〃 INCONEL 0.9 Standard 400A Mig_3 DC-Pulse φ0.9 Inconel (Low) $WTBD3736
〃 〃 〃 1.2 〃 400A Mig_3 DC-Pulse φ1.2 Inconel (Low) $WTBD3737
DC
wave
pulse
MAG
Mild Steel
Solid
0.8 〃 400A Mag DC-Wave φ0.8 (Low) $WTBD3740
〃 MIG※2 SUS 0.8 〃 400A Mig_4 DC-Wave φ0.8 SuS (Low) $WTBD3753
DC
pulse
MAG
Mild Steel
Solid
0.8 〃 400A Mag DC-Pulse φ0.8 (Low) $WTBD3754
DC
wave
pulse
MIG※2 Ferrite 0.8 〃 400A Mig_4 DC-Wave φ0.8 Ferrite (Low) $WTBD3757
〃 〃 〃 0.9 〃 400A Mig_4 DC-Wave φ0.9 Ferrite (Low) $WTBD3758
〃 〃 〃 1.2 〃 400A Mig_4 DC-Wave φ1.2 Ferrite (Low) $WTBD3760
DC MAG
Mild Steel
Cored
1.2
Extended
cable
400A Mag DC φ1.2 (Cored) (Low*) $WTBD3762
〃 〃 SUS Cored 1.2 〃 400A Mag DC φ1.2 SuS(Cored) (Low*) $WTBD3763
〃 MIG※2 Ferrite 1.0 〃 400A Mig_4 DC φ1.0 Ferrite (Low*) $WTBD3774
〃 〃 〃 1.2 〃 400A Mig_4 DC φ1.2 Ferrite (Low*) $WTBD3775
DC
pulse
MAG
Mild Steel
Solid
1.4 High 400A Mag DC-Pulse φ1.4 (High) $WTBD3776
〃 〃 〃 1.4 Standard 400A Mag DC-Pulse φ1.4 (Low) $WTBD3777
DC
wave
pulse
〃 〃 1.4 High 400A Mag DC-Wave φ1.4 (High) $WTBD3778
〃 〃 〃 1.4 Standard 400A Mag DC-Wave φ1.4 (Low) $WTBD3779
DC MIG※1 Cu-Si 0.9
Extended
cable
400A Mig_3 DC φ0.9 Cu-Si (Low*) $WTBD3780
〃 〃 〃 1.2 〃 400A Mig_3 DC φ1.2 Cu-Si (Low*) $WTBD3781
〃 MIG※2 Ferrite 0.8 High 400A Mig_4 DC φ0.8 Ferrite (High) $WTBD3782
〃 〃 〃 0.9 〃 400A Mig_4 DC φ0.9 Ferrite (High) $WTBD3783
〃 〃 〃 0.8 Standard 400A Mig_4 DC φ0.8 Ferrite (Low) $WTBD3784
〃 〃 〃 0.9 〃 400A Mig_4 DC φ0.9 Ferrite (Low) $WTBD3785
〃 〃 〃 0.8
Extended
cable
400A Mig_4 DC φ0.8 Ferrite (Low*) $WTBD3786
〃 〃 〃 0.9 〃 400A Mig_4 DC φ0.9 Ferrite (Low*) $WTBD3787
※1 100%Ar
※2 98%Ar, 2%O
2
POINT
Normally, use the welding characteristic data given in Table 1.4.11 dedicated to “High”
application. The ones for “Standard” application must be used only when the welding
speed is low (50cm/min or lower in general), which causes unstable welding
performance.
Also, welding performance may become unstable when using the extended power cable
depending on the layout condition of cables (when the total length exceeds 30m or the
cable is coiled). In that case, voltage adjustment will normally bring about stable
condition. However, use the welding characteristic data dedicated to “Standard:
extension” application if the welding performance is not yet stable. In order to register
“Standard: extension” application, change the operator qualification to “
SPECIALIST
”.)
To Next Page
