1.4 Welding mode lists
1-44
Welding mode
Welding
process
Gas
Wire
material
Wire
diameter
Travel
speed
Welding mode description
Notes
Number of welding
characteristic data
in AX21/FD11
DC
pulse
MAG
Mild Steel
Solid
1.0 Standard
400A Mag DC-Pulseφ1.0 (Low)
$WTBD3554
〃 〃 〃 1.2 〃
400A Mag DC-Pulseφ1.2 (Low)
$WTBD3555
〃 MIG※1 SUS 0.9 〃
400A Mig_4 DC-Pulseφ0.9 SuS
(Low)
$WTBD3556
〃 〃 〃 1.0 〃
400A Mig_4 DC-Pulseφ1.0 SuS
(Low)
$WTBD3557
〃 〃 〃 1.2 〃 400A Mig_4 DC-Pulseφ1.2 SuS (Low) $WTBD3558
〃 MIG※2 Hard Alm 1.0 〃 400A Mig_3 DC-Pulseφ1.0 Hard Al (Low) $WTBD3559
〃 〃 〃 1.2 〃 400A Mig_3 DC-Pulseφ1.2 Hard Al (Low) $WTBD3560
〃 〃 〃 1.6 〃 400A Mig_3 DC-Pulseφ1.6 Hard Al (Low) $WTBD3561
〃 〃 Soft Alm 1.2 〃 400A Mig_3 DC-Pulseφ1.2 Soft Al (Low) $WTBD3562
〃 〃 〃 1.6 〃
400A Mig_3 DC-Pulseφ1.6 Soft Al
(Low)
$WTBD3563
DC CO2
Mild Steel
Solid
0.8
Extended
cable
400A Co2 DCφ0.8 (Low*) $WTBD3564
〃 〃 〃 0.9 〃 400A Co2 DCφ0.9 (Low*) $WTBD3565
〃 〃 〃 1.0 〃 400A Co2 DCφ1.0 (Low*) $WTBD3566
〃 〃 〃 1.2 〃 400A Co2 DCφ1.2 (Low*) $WTBD3567
〃 〃
Mild Steel
Cored
1.0 〃 400A Co2 DCφ1.0 (Cored) (Low*) $WTBD3568
〃 〃 〃 1.2 〃 400A Co2 DCφ1.2 (Cored) (Low*) $WTBD3569
〃 〃 SUS Cored 1.0 〃 400A Co2 DCφ1.0 SuS(Cored) (Low*) $WTBD3570
〃 〃 〃 1.2 〃 400A Co2 DCφ1.2 SuS(Cored) (Low*) $WTBD3571
〃 MAG
Mild Steel
Solid
0.8 〃 400A Mag DCφ0.8 (Low*) $WTBD3572
〃 〃 〃 0.9 〃 400A Mag DCφ0.9 (Low*) $WTBD3573
〃 〃 〃 1.0 〃 400A Mag DCφ1.0 (Low*) $WTBD3574
〃 〃 〃 1.2 〃 400A Mag DCφ1.2 (Low*) $WTBD3575
〃 MIG※1 SUS 0.8 〃 400A Mig_4 DCφ0.8 SuS (Low*) $WTBD3576
〃 〃 〃 0.9 〃 400A Mig_4 DCφ0.9 SuS (Low*) $WTBD3577
〃 〃 〃 1.0 〃 400A Mig_4 DCφ1.0 SuS (Low*) $WTBD3578
〃 〃 〃 1.2 〃
400A Mig_4 DCφ1.2 SuS (Low*)
$WTBD3579
〃 MIG※2 Hard Alm 1.0 〃 400A Mig_3 DCφ1.0 Hard Al (Low*) $WTBD3580
〃 〃 〃 1.2 〃 400A Mig_3 DCφ1.2 Hard Al (Low*) $WTBD3581
〃 〃 〃 1.6 〃 400A Mig_3 DCφ1.6 Hard Al (Low*) $WTBD3582
〃 〃 Soft Alm 1.2 〃 400A Mig_3 DCφ1.2 Soft Al (Low*) $WTBD3583
〃 〃 〃 1.6 〃 400A Mig_3 DCφ1.6 Soft Al (Low*) $WTBD3584
DC
wave
pulse
MAG
Mild Steel
Solid
0.9 High 400A Mag DC-Waveφ0.9 (High) $WTBD3585
〃 〃 〃 1.0 〃 400A Mag DC-Waveφ1.0 (High) $WTBD3586
〃 〃 〃 1.2 〃
400A Mag DC-Waveφ1.2 (High)
$WTBD3587
〃 MIG※1 SUS 0.9 〃 400A Mig_4 DC-Waveφ0.9 SuS (High) $WTBD3588
〃 〃 〃 1.0 〃 400A Mig_4 DC-Waveφ1.0 SuS (High) $WTBD3589
〃 〃 〃 1.2 〃 400A Mig_4 DC-Waveφ1.2 SuS (High) $WTBD3590
〃 MIG※2 Hard Alm 1.2 〃 400A Mig_3 DC-Wave φ1.2 Hard Al (High) $WTBD3591
〃 〃 〃 1.6 〃 400A Mig_3 DC-Waveφ1.6 Hard Al (High) $WTBD3592
〃 〃 Soft Alm 1.2 〃 400A Mig_3 DC-Waveφ1.2 Soft Al (High) $WTBD3593
DC
wave
pulse
MIG※2 Soft Alm 1.6 High
400A Mig_3 DC-Waveφ1.6 Soft Al
(High)
$WTBD3594
〃 MAG
Mild Steel
Solid
0.9 Standard
400A Mag DC-Waveφ0.9 (Low)
$WTBD3595
〃 〃 〃 1.0 〃
400A Mag DC-Waveφ1.0 (Low)
$WTBD3596
〃 〃 〃 1.2 〃
400A Mag DC-Waveφ1.2 (Low)
$WTBD3597
〃 MIG※1 SUS 0.9 〃 400A Mig_4 DC-Waveφ0.9 SuS (Low) $WTBD3598
〃 〃 〃 1.0 〃 400A Mig_4 DC-Waveφ1.0 SuS (Low) $WTBD3599
〃 〃 〃 1.2 〃 400A Mig_4 DC-Waveφ1.2 SuS (Low) $WTBD3600
〃 MIG※2 Hard Alm 1.2 〃 400A Mig_3 DC-Waveφ1.2 Hard Al (Low) $WTBD3601
〃 〃 〃 1.6 〃 400A Mig_3 DC-Waveφ1.6 Hard Al (Low) $WTBD3602
〃 〃 Soft Alm 1.2 〃 400A Mig_3 DC-Waveφ1.2 Soft Al (Low) $WTBD3603
〃 〃 〃 1.6 〃
400A Mig_3 DC-Waveφ1.6 Soft Al
(Low)
$WTBD3604
