1.4 Welding mode lists
1-66
Welding mode
Welding
process
Gas
Wire
material
Wire
diameter
Travel
speed
Welding mode description
Notes
Number of welding
characteristic data
in AX21/FD11
DC
wave
pulse
MIG※1 SUS 0.8 High 500A Mig_4 DC-Waveφ0.8 SuS(High) $WTBD4079
〃 〃 〃 0.9 〃 500A Mig_4 DC-Waveφ0.9 SuS(High) $WTBD4080
〃 〃 〃 1.0 〃
500A Mig_4 DC-Waveφ1.0 SuS(High)
$WTBD4081
〃 〃 〃 1.2 〃 500A Mig_4 DC-Wave φ1.2 SuS(High) $WTBD4082
〃 〃 〃 1.6 〃 500A Mig_4 DC-Wave φ1.6 SuS(High) $WTBD4083
〃 〃 Ferrite 0.8 〃 500A Mig_4 DC-Waveφ0.8 Ferrite(High) $WTBD4084
〃 〃 〃 0.9 〃 500A Mig_4 DC-Waveφ0.9 Ferrite(High) $WTBD4085
〃 〃 〃 1.0 〃 500A Mig_4 DC-Waveφ1.0 Ferrite(High) $WTBD4086
〃 〃 〃 1.2 〃 500A Mig_4 DC-Waveφ1.2 Ferrite(High) $WTBD4087
〃 MIG※2 Hard Alm 1.0 〃 500A Mig_3 DC-Wave φ1.0 Hard Al(High) $WTBD4088
〃 〃 〃 1.2 〃 500A Mig_3 DC-Wave φ1.2 Hard Al(High) $WTBD4089
〃 〃 〃 1.6 〃 500A Mig_3 DC-Wave φ1.6 Hard Al(High) $WTBD4090
〃 〃 Soft Alm 1.2 〃 500A Mig_3 DC-Wave φ1.2 Soft Al(High) $WTBD4091
〃 〃 〃 1.6 〃 500A Mig_3 DC-Wave φ1.6 Soft Al(High) $WTBD4092
〃 MAG
Mild Steel
Solid
0.8 Standard 500A Mag DC-Wave φ0.8(Low) $WTBD4093
〃 〃 〃 0.9 〃 500A Mag DC-Wave φ0.9(Low) $WTBD4094
〃 〃 〃 1.0 〃 500A Mag DC-Wave φ1.0(Low) $WTBD4095
〃 〃 〃 1.2 〃 500A Mag DC-Wave φ1.2(Low) $WTBD4096
〃 〃 〃 1.4 〃 500A Mag DC-Wave φ1.4(Low) $WTBD4097
〃 〃 〃 1.6 〃 500A Mag DC-Wave φ1.6(Low) $WTBD4098
〃 MIG※1 SUS 0.8 〃 500A Mig_4 DC-Waveφ0.8 SuS(Low) $WTBD4099
〃 〃 〃 0.9 〃 500A Mig_4 DC-Waveφ0.9 SuS(Low) $WTBD4100
〃 〃 〃 1.0 〃
500A Mig_4 DC-Waveφ1.0 SuS(Low)
$WTBD4101
〃 〃 〃 1.2 〃 500A Mig_4 DC-Wave φ1.2 SuS(Low) $WTBD4102
〃 〃 〃 1.6 〃 500A Mig_4 DC-Wave φ1.6 SuS(Low) $WTBD4103
〃 〃 Ferrite 0.8 〃 500A Mig_4 DC-Waveφ0.8 Ferrite(Low) $WTBD4104
〃 〃 〃 0.9 〃 500A Mig_4 DC-Waveφ0.9 Ferrite(Low) $WTBD4105
〃 〃 〃 1.0 〃 500A Mig_4 DC-Waveφ1.0 Ferrite(Low) $WTBD4106
〃 〃 〃 1.2 〃 500A Mig_4 DC-Waveφ1.2 Ferrite(Low) $WTBD4107
〃 MIG※2 Hard Alm 1.0 〃 500A Mig_3 DC-Wave φ1.0 Hard Al(Low) $WTBD4108
〃 〃 〃 1.2 〃 500A Mig_3 DC-Wave φ1.2 Hard Al(Low) $WTBD4109
〃 〃 〃 1.6 〃 500A Mig_3 DC-Wave φ1.6 Hard Al(Low) $WTBD4110
〃 〃 Soft Alm 1.2 〃 500A Mig_3 DC-Wave φ1.2 Soft Al(Low) $WTBD4111
〃 〃 〃 1.6 〃 500A Mig_3 DC-Wave φ1.6 Soft Al(Low) $WTBD4112
※1 98%Ar, 2%O
2
※2 100%Ar
POINT
Normally, use the welding characteristic data given in Table 1.4.18 dedicated to “High”
application. The ones for “Standard” application must be used only when the welding
speed is low (50cm/min or lower in general), which causes unstable welding performance.
Set the welding speed to 100～200cm/min. for the welding characteristic data with the use
for “High-speed pulse”.
When the wire material is a steel/SUS/Ferrite, make a connection as indicated in Chapter
1 “1.2.8 Connection of Voltage detecting cable (workpiece side)”, and go to <Arc constant>
- [3 Constant of weld] – [Arc voltage direct detection] to set “ON”.
Welding performance may become unstable when using the extended power cable
depending on the layout condition of cables (when the total length exceeds 30m or the
cable is coiled). In that case, voltage adjustment will normally bring about stable condition.
However, use the welding characteristic data dedicated to “Standard: extension”
application if the welding performance is not yet stable. In order to register “Standard:
extension” application, change the operator qualification to “
SPECIALIST
”.)
To Next Page
