1.4 Welding mode lists
1-65
Welding mode
Welding
process
Gas
Wire
material
Wire
diameter
Travel
speed
Welding mode description
Notes
Number of welding
characteristic data
in AX21/FD11
DC
pulse
MAG
Mild Steel
Solid
0.9 Standard 500A Mag DC-Pulse φ0.9(Low) $WTBD4021
〃 〃 〃 1.0 〃 500A Mag DC-Pulse φ1.0(Low) $WTBD4022
〃 〃 〃 1.2 〃 500A Mag DC-Pulse φ1.2(Low) $WTBD4023
〃 〃 〃 1.4 〃 500A Mag DC-Pulse φ1.4(Low) $WTBD4024
〃 〃 〃 1.6 〃 500A Mag DC-Pulse φ1.6(Low) $WTBD4025
〃 MIG※1 SUS 0.8 〃 500A Mig_4 DC-Pulseφ0.8 SuS(Low) $WTBD4026
〃 〃 〃 0.9 〃 500A Mig_4 DC-Pulseφ0.9 SuS(Low) $WTBD4027
〃 〃 〃 1.0 〃
500A Mig_4 DC-Pulseφ1.0 SuS(Low)
$WTBD4028
〃 〃 〃 1.2 〃 500A Mig_4 DC-Pulse φ1.2 SuS(Low) $WTBD4029
〃 〃 〃 1.6 〃 500A Mig_4 DC-Pulse φ1.6 SuS(Low) $WTBD4030
〃 〃 Ferrite 0.8 〃 500A Mig_4 DC-Pulse φ0.8 Ferrite(Low) $WTBD4031
〃 〃 〃 0.9 〃 500A Mig_4 DC-Pulse φ0.9 Ferrite(Low) $WTBD4032
〃 〃 〃 1.0 〃 500A Mig_4 DC-Pulse φ1.0 Ferrite(Low) $WTBD4033
〃 〃 〃 1.2 〃 500A Mig_4 DC-Pulse φ1.2 Ferrite(Low) $WTBD4034
〃 MIG※2 Hard Alm 1.0 〃 500A Mig_3 DC-Pulse φ1.0 Hard Al(Low) $WTBD4035
〃 〃 〃 1.2 〃 500A Mig_3 DC-Pulse φ1.2 Hard Al(Low) $WTBD4036
〃 〃 〃 1.6 〃 500A Mig_3 DC-Pulse φ1.6 Hard Al(Low) $WTBD4037
〃 〃 Soft Alm 1.2 〃 500A Mig_3 DC-Pulse φ1.2 Soft Al(Low) $WTBD4038
〃 〃 〃 1.6 〃 500A Mig_3 DC-Pulse φ1.6 Soft Al(Low) $WTBD4039
DC CO2
Mild Steel
Solid
0.8
Extended
cable
500A Co2 DC φ0.8(Low*)
$WTBD4040
〃 〃 〃 0.9 〃 500A Co2 DC φ0.9(Low*) $WTBD4041
〃 〃 〃 1.0 〃 500A Co2 DC φ1.0(Low*) $WTBD4042
〃 〃 〃 1.2 〃 500A Co2 DC φ1.2(Low*) $WTBD4043
〃 〃 〃 1.4 〃 500A Co2 DC φ1.4(Low*) $WTBD4044
〃 〃 〃 1.6 〃 500A Co2 DC φ1.6(Low*) $WTBD4045
〃 〃
Mild Steel
Cored
1.0 〃 500A Co2 DC φ1.0 (Cored) (Low*) $WTBD4046
〃 〃 〃 1.2 〃 500A Co2 DC φ1.2 (Cored) (Low*) $WTBD4047
〃 〃 〃 1.4 〃 500A Co2 DC φ1.4 (Cored) (Low*) $WTBD4048
〃 〃 〃 1.6 〃 500A Co2 DC φ1.6 (Cored) (Low*) $WTBD4049
〃 〃 SUS Cored 0.9 〃
500A Co2 DC φ0.9 SuS(Cored) (Low*)
$WTBD4050
〃 〃 〃 1.2 〃
500A Co2 DC φ1.2 SuS(Cored) (Low*)
$WTBD4051
〃 〃 〃 1.6 〃
500A Co2 DC φ1.6 SuS(Cored) (Low*)
$WTBD4052
〃 MAG
Mild Steel
Solid
0.8 〃
500A Mag DC φ0.8(Low*)
$WTBD4053
〃 〃 〃 0.9 〃 500A Mag DC φ0.9(Low*) $WTBD4054
〃 〃 〃 1.0 〃 500A Mag DC φ1.0(Low*) $WTBD4055
〃 〃 〃 1.2 〃 500A Mag DC φ1.2(Low*) $WTBD4056
〃 〃 〃 1.4 〃 500A Mag DC φ1.4(Low*) $WTBD4057
〃 〃 〃 1.6 〃 500A Mag DC φ1.6(Low*) $WTBD4058
〃 MIG※1 SUS 0.8 〃 500A Mig_4 DC φ0.8 SuS(Low*) $WTBD4059
〃 〃 〃 0.9 〃 500A Mig_4 DCφ0.9 SuS(Low*) $WTBD4060
〃 〃 〃 1.0 〃
500A Mig_4 DCφ1.0 SuS(Low*)
$WTBD4061
〃 〃 〃 1.2 〃 500A Mig_4 DC φ1.2 SuS(Low*) $WTBD4062
〃 〃 〃 1.6 〃 500A Mig_4 DC φ1.6 SuS(Low*) $WTBD4063
〃 〃 Ferrite 0.8 〃 500A Mig_4DC φ0.8 Ferrite(Low*) $WTBD4064
〃 〃 〃 0.9 〃 500A Mig_4DC φ0.9 Ferrite(Low*) $WTBD4065
〃 〃 〃 1.0 〃 500A Mig_4DC φ1.0 Ferrite(Low*) $WTBD4066
〃 〃 〃 1.2 〃 500A Mig_4DC φ1.2 Ferrite(Low*) $WTBD4067
〃 MIG※2 Hard Alm 1.0
〃
500A Mig_3 DC φ1.0 Hard Al(Low*) $WTBD4068
〃 〃 〃 1.2 〃 500A Mig_3 DC φ1.2 Hard Al(Low*) $WTBD4069
〃 〃 〃 1.6 〃 500A Mig_3 DC φ1.6 Hard Al(Low*) $WTBD4070
〃 〃 Soft Alm 1.2 〃 500A Mig_3 DC φ1.2 Soft Al(Low*) $WTBD4071
〃 〃 〃 1.6 〃 500A Mig_3 DC φ1.6 Soft Al(Low*) $WTBD4072
DC
wave
pulse
MAG
Mild Steel
Solid
0.8 High 500A Mag DC-Wave φ0.8(High) $WTBD4073
〃 〃 〃 0.9 〃 500A Mag DC-Wave φ0.9(High) $WTBD4074
〃 〃 〃 1.0 〃 500A Mag DC-Wave φ1.0(High) $WTBD4075
〃 〃 〃 1.2 〃 500A Mag DC-Wave φ1.2(High) $WTBD4076
〃 〃 〃 1.4 〃 500A Mag DC-Wave φ1.4(High) $WTBD4077
〃 〃 〃 1.6 〃 500A Mag DC-Wave φ1.6(High) $WTBD4078
