Screen 1 Monitoring
1.
On Screen 1 Monitoring, select a zone
or a group from the button 1 .
Change the fan direction or volume of air
conditioners.
On the Monitoring screen, operation is allowed
with either Icon or List as the display type.
The fan direction or volume can be changed by
zone or by group.
2.
Select a zone or a group of which the
fan direction or volume is to be reset 2 .
3.
4.
Press the [Advanced Operation] button 4 .
Screen 3 Advance Operation appears.
Select between High and Low with the
pull-down menu 5 .
To cancel the setting, press the
[Cancel] button.
Screen 2 Operation reappears.
5.
Changing the Direction / Fan Speed
Screen 2 Operation
6.
To cancel the setting, press the
[Cancel] button.
1
2
3
4
5
6
8
7
Screen 3 Advanced Operation
The larger the value for wind direction
setting (0 - 6), the closer to vertical the
direction becomes. The value 7
indicates automatic swing.
(Note: See the figure below.)
The description given above may not
exactly apply depending on the model.
Check the wind direction sign on the
remote control after operation.
Then press the [OK] button 7 .
0
4
5
6
Indoor unit
[Procedure]
Press the [Set] button 3 .
Screen 2 Operation appears.
Set the direction with the pull-down
menu 6 .
Then press the
[OK] button 8 on Screen
2 Operation.
Note: Guidelines for wind direction value and
actual direction
7: Wind direction auto
swing
