Spyder3 S3-14 and S3-24 Monochrome Camera User's Manual 73
Teledyne DALSA 03-032-20117-01
Returns the current state of the camera’s LED w here:
1 = Red
2 = Green
5 = Blinking green
6 = Blinking red
Display the online help. Refer to the Select Cable Camera
ASCII Command Help for details.
Loads the previously saved pixel coefficients from non-
volatile memory where i is:
0 = Factory calibrated coefficients
1 = Coefficient set one
2 = Coefficient set two
3 = Coefficient set three
4 = Coefficient set four
Resets the entire camera (reboot). Baud rate is not reset
and reboots with the value last used.
Restores the cam era’s factory settings. FPN and PRN U
coefficients reset to 0.
Sets the value of the current LUT to zero. Use wil to save
this setting.
Sets the pixel range affected by the cag, gl, gla, ccf,
and ccp commands. The parameters are the pixel start
and end values (x) and the column start and end values
(y) in a range from 1 to sensor pixel count.
Resets the pixel coefficients to 0.
Restores the camera's last saved user settings and FPN
and PRNU coefficients.
Sets the analog gain in dB.
t = tap selection, either 1 or 2 depending on camera
model, or 0 for all taps.
f= gain value specified from –10 to +10
Sets the analog offset.
t = tap selection, either 1 or 2 depending on camera
model, or 0 for all taps.
i= Offset value in a range from 0 to 255 (12-bit LSB).
Offset increases with higher values.
Sets the horizontal binning value. Available values are 1
and 2.
Set the speed of camera serial communication port. Baud
rates: 9600, 19200, 57600, and 115200. Default: 9600.
Set the cable parameter. Output compare value.
Available values are: 0-255.
