TECHNICAL FEATURES
99
12
12 TECHNICAL FEATURES
ELECTRICAL FEATURES
Supply Voltage 15 to 30 Vdc
Power Consumption 15 W typical
1.3 to 0.5 A max. (including startup current)
Main Baud Rate
RS232
RS485 full-duplex
RS485 half-duplex
1200 to 115200
Auxiliary
RS232 1200 to 115200
Other
Common Communication
Interfaces
Lonworks 1.25 Mb/s
Model–Dependent Communication
Interfaces
Ethernet
DeviceNet
Profibus
100 Mb/s
up to 500 Kb/s
up to 12 Mb/s
Inputs
Ext. Trigger 1, Encoder
2 aux. digital inputs
(optocoupled NPN or PNP)
Outputs
3 software programmable digital
outputs
(optocoupled)
OPTICAL FEATURES
Light Receiver Avalanche photodiode
Wavelength 630 to 680 nm
Safety Class Class 2 - EN60825-1; Class II - CDRH
Laser Control Security system to turn laser off in case of motor slow
down
READING FEATURES
Scan Rate 600-1200 scans/s
Maximum Resolution
Max. Reading Distance
Max. Reading Width
Max. Depth of Field
(see reading diagrams in par. 9.4)
USER INTERFACE
LCD Display 2 lines by 16 characters LCD
Keypad 3 keys
LED Indicators Power On (red)
Phase On (yellow)
TX Data (green)
