DS6300 REFERENCE MANUAL
48
4
DS
6
30
0
USER INTERFACE
V
ext 100 Vdc max
A/B
B/
A
Figure 68 – Output 3 Interface
The command signals are filtered and generate a delay of about 50 µs for Output 1 and 2
and 1 ms for Output 3.
4.6 USER INTERFACE
How To Build A Simple Interface Test Cable:
The following wiring diagram shows a simple test cable including power, external
(push-button) trigger and PC RS232 COM port connections.
25-pin D-sub female
2
3
20
GND
RX AUX
TX AUX
21
DS6300
25
1
3
GND
V
S
9-pin D-sub female
GND
TX
RX
PC
2
3
5
1
8
9
EXT TRIG
A
V
S
Power Supply
VS (15 – 30 VDC)
Power GND
Trigger
EXT TRIG B1
9
Test Cable for DS6300
