DS6300 REFERENCE MANUAL
88
9
9.4.2 DS6300 Oscillating Mirror Model
DS6300-105-0XX (oscillating mirror) - Resolution: 0.20 mm/8 mils
4
2
0
6
(in)
0 6 12
(in)
8 10 14 16
0 15 20 25 30 35 40 45 50
(cm)
25
20
15
10
0
(cm)
5
-5
-10
-15
-20
-25
8
10
-8
-10
-6
-4
-2
55 60
2018 22 24
Focus
Position = 40
Focus
Position = 0
Figure 107 – Oscillating Mirror Model 0.20 mm / 8 mils Reading Diagram
CONDITIONS
Code = Interleaved 2/5 or Code 39
PCS = 0.90
Pitch angle = 0°
Skew angle = 10° - 20°
Tilt angle = 0°
Note: (0,0) is the center of the laser beam output window.
