Datalogic DS6300 User Manual

READING FEATURES
87
9
DS6300-100-0XX - Resolution: 0.50 mm/20 mils
8
4
0
12
(in)
0 8 20
(in)
12 16 24 28
0 20 30 40 50 60 70 80 90
(cm)
50
40
30
20
0
(cm)
10
-10
-20
-30
-40
-50
16
20
-16
-20
-12
-8
-4
100
3632 40 44
Focus
Position = 60
-60
-24
60
24
48
52 56
Focus
Position = 100
110 120 130 140
Focus
Position = 0
150
Figure 106 - Standard Model 0.50 mm / 20 mils Reading Diagram
CONDITIONS
Code = Interleaved 2/5 or Code 39
PCS = 0.90
Pitch angle = 0°
Skew angle = 10° - 20°
Tilt angle = 0°
Note: (0,0) is the center of the laser beam output window.
