DS6300 REFERENCE MANUAL
86
9
DS6300-100-0XX - Resolution: 0.38 mm/15 mils
4
2
0
6
(in)
0 12 18
(in)
14 16 20 22
0 30 35 40 45 50 55
(cm)
25
20
15
10
0
(cm)
5
-5
-10
-15
-20
-25
8
10
-8
-10
-6
-4
-2
60 65
2624 28 30
Focus
Position = 0
-30
-12
30
12
70 75 80 85
3432 36 38
Focus
Position = 60
90 95 100 105 110
35
40
-35
-40
Focus
Position = 100
40 42 44
14
16
-14
-16
Figure 105 - Standard Model 0.38 mm / 15 mils Reading Diagram
CONDITIONS
Code = Interleaved 2/5 or Code 39
PCS = 0.90
Pitch angle = 0°
Skew angle = 10° - 20°
Tilt angle = 0°
Note: (0,0) is the center of the laser beam output window.
