DS6300 REFERENCE MANUAL
36
4
4 CUSTOM CABLE ELECTRICAL CONNECTIONS
Each scanner model has the following connectors:
Scanner Model Connectors
Master/Slave 25-pin male serial interface and I/O connector
9-pin male Lonworks connector (see caution below)
9-pin female Lonworks connector
Ethernet 26-pin male serial interface and I/O connector
9-pin female Lonworks connector
M12 4-pin D-coded connector for Ethernet *
DeviceNet 26-pin male serial interface and I/O connector
9-pin female Lonworks connector
5-pin male connector
Profibus 26-pin male serial interface and I/O connector
9-pin female Lonworks connector
9-pin female Profibus connector
* older models have RJ45 modular connector for Ethernet
CAUTION
Do not connect an RS232 port to the 9-pin Lonworks Connector. This may
damage your Laptop PC.
DS6300 scanners are equipped with a 25-pin male D-sub connector (Master/Slave models)
or a 26-pin male D-sub connector (Fieldbus models) for connection to the host computer,
power supply and input/output signals. These signals can be wired using a custom cable
according to the application needs.
The paragraphs in this chapter detail the individual signal connections.
For Lonworks network connections see chapters 5 and 7.
For Fieldbus connection
s see chapters 6 and 7.
For ID-NET
™ Fixed Baudrate connections see the Application Note on the CD-ROM.
