Fieldbus Models
In this case no External Trigger is used and the CBX100/CBX500 only passes power to the
reader. The DS6300 Fieldbus models (Ethernet, DeviceNet or Profibus) are connected to a
remote Host. It can be activated by a signal generated by the remote Host or always be
active if working in Automatic operating mode.
Figure 116 – Point-to-Point for Fieldbus Models
Remote Host
CBX
CAB-F0x
PWR-120
Fieldbus
Network
I/O, AUX
DS6300
Fieldbus
model
