Datalogic DS6300 User Manual

xii
Figure D – Connector Panel for Master/Slave Models
Main/Aux. Interface 25-pin D-Sub male connector
1
Lonworks 9-pin male connector
2
Lonworks 9-pin female connector
3
Figure E – Connector Panel for Ethernet Models
Main/Aux. Interface 26-pin D-Sub male connector
1
Ethernet 4-pin female connector
2
Lonworks 9-pin female connector
3
Figure F – Connector Panel for (older) Ethernet Models
Main/Aux. Interface 26-pin D-Sub male connector
1
RJ45 modular connector for Ethernet Interface
2
Lonworks 9-pin female connector
3
3
2
1
3
2
1
2
1
3
