Datalogic DS6300 User Manual

CUSTOM CABLE ELECTRICAL CONNECTIONS
45
4
INPUT 1 - 2 CONNECTIONS USING EXTERNAL POWER
E XTE RN AL TRIG GE R/E NCODE
R
DS6300
+ 5V
A/B
Vext
B/
A
V
~
~
+
-
Grou nd
Figure 63 – PNP Command Input Connection Using External Power
EXTERNAL TRIGGER/ENCODE
R
DS
6
3
0
0
A/B
Vext
B/
A
V
+ 5V
~
~
+
-
Groun d
Figure 64 - NPN Command Input Connection Using External Power
NOTE
Terminal pins I34B are common to both inputs 3 and 4 and therefore these
inputs cannot be driven by opposite polarity devices.
INPUT 3 - 4 CONNECTIONS USING DS6300 POWER
EXTERNAL DEVICE
DS
6
3
00
I3A
Gro und
V
+ 5V
~
~
+
-
EXTERNAL DEVICE
GND
V
I4 A
+ 5V
~
~
+
-
I34B
Vdc
Ground
Figure 65 - I3/I4 NPN Input Command using Scanner Power
