Adjustments and Maintenance
2-11
8. Install media. Test the calibration by pressing FEED. A label should feed from the
printer. Press CANCEL. A Test Label should be produced.
Note: To discard calibration changes and revert to the previous settings, turn OFF the
printer before performing Step 9.
9. Simultaneously press PAUSE and CANCEL briefly. Wait until the STOP Light goes OFF.
The printer is ready for operation.
2.2.2 Calibrating Display-Equipped Models
Three different calibration methods are available.
2.2.2.1 Quick Calibration
This is the easiest calibration method.
Note: Quick Calibration is not required for continuous media. If UNCALIBRATED is
displayed, use Standard Calibration (Section 2.2.2.2).
Perform a Quick Calibration as follows:
1. Ensure that media is loaded, that the Media Sensor is adjusted, and that the printer is
idle.
2. Press and hold FEED.
The printer will begin advancing media; allow at least one label gap or mark to pass
through the sensor. Upon successful completion, CALIBRATION COMPLETE will be
displayed, as the label is advanced to the next TOF and READY appears. (WARNING
LOW BACKING may appear if using notched media or media on a transparent liner;
however, the calibration was successful).
Note: Media with large TOF spaces may require a change in the PAPER EMPTY
DISTANCE.
