Datamax M-Class Mark II Maintenance Manual

Troubleshooting
3-1
3.0 Overview
This chapter covers techniques for isolating and correcting printer problems.
3.1 Troubleshooting
Use the following procedures to isolate and correct malfunctions. When problems are
isolated to a Printed Circuit Board (PCB), assembly replacement is suggested, as component
level repair is not generally feasible in the field.
 Note: Unless otherwise noted, see the Operator’s Manual for configuration, interfacing
and setup information.
3.1.1 Initial Steps
CAUTION
(1) Before servicing always unplug the printer; (2) ensure that the unit has
been placed on a level, stable surface; and, (3) use extreme care if measuring
voltages.
Perform the following actions before troubleshooting then proceed according to the
symptom:
• Remove any dirt or dust accumulations (see Section 2.1);
• Confirm that the AC outlet voltage is within specification;
• Confirm that the environment is acceptable;
• Confirm correct media and loading; and,
• If installed, disable the Present Sensor.
3.2 General Problem Resolution
To troubleshoot non-display models, or display-equipped models when no message is
generated, begin with Problem Isolation (Section 3.2.1). Follow the instruction under
Procedure then take the appropriate Action to find the defective item (listed by probability)
or, when necessary, further instructions.

Datamax M-Class Mark II Specifications

General

Media Sensor	Adjustable reflective and transmissive sensors
Print Method	Thermal Transfer
Print Resolution	203 dpi
Memory	8 MB Flash, 16 MB SDRAM
Interface Options	USB, Serial, Ethernet, Parallel
Media Type	Roll-fed, die-cut, continuous, fan-fold, tags, ticket stock
Media Width	1.0 in (25.4 mm) to 4.65 in (118 mm)
Media Thickness	0.0025 in (0.0635 mm) to 0.010 in (0.254 mm)
Media Roll Diameter	8 inches (203 mm) max
Ribbon Width	1 to 4.33 inches (25.4 to 110 mm)
Ribbon Length	1968 ft (600 m)
Ribbon Core	1 inch (25.4 mm)
Label Width Range	1.0 in (25.4 mm) to 4.65 in (118 mm)
Label Length Range	0.25 to 39 inches (6.35 to 991 mm)
