Overview
1-2
1.1 About this Printer
The following drawing illustrates the basic exterior components and controls of the printer.
The model number can be found on the Serial Tag affixed to the rear of the unit. Use this
model number when referencing specific information within this manual. (Because optional
items are not present on all models, certain printer configurations may not appear in some
of the illustrations in this manual.)
Centerplate
Access Cover
Front Panel
Ribbon Take-Up Hub
Ribbon Supply Hub
Media Supply Assembly
(Hanger or Hub)
Internal Rewinder
Printhead Assembly
Ribbon Idler
Media Sensor
Printhead Latch
Media Guide
Fascia
Media Idler
