Datamax M-Class Mark II Maintenance Manual

Troubleshooting
3-14
Fault Messages (continued)
Displayed Message Description Possible Solution(s)
CUTTER FAULT
Blade positioning has
failed.
Cycle power OFF and ON. Then,
ensure that media thickness is
within specification for the cutter.
Retry. If the fault continues, try the
following:
WARNING! Turn OFF and
unplug the printer before
proceeding.
1) Ensure that the cutter is properly
installed and that the cable is
connected and undamaged.
2) Clean the cutter and ensure that
the mechanism is unobstructed.
3) The cutter may be defective;
replace it.
4) The Main Logic PCB may be
defective; see Section 4.4.
DMA FAULT
Direct Memory Access
has failed.
Cycle power OFF and ON. If the
fault does not clear, replace the
Main Logic PCB; see Section 4.4.
GAP MODE
CANNOT CALIBRATE
Consistently low sensor
readings have occurred.
Press any key to continue then try
the following:
1) Retry calibration, ensuring that
media was inserted in the sensor
during the appropriate step.
2) Clean the sensor (see Section
2.1.2) then retry calibration.
3) Try Advanced Entry Calibration;
see Section 2.2.2.3.

Datamax M-Class Mark II Specifications

General

Media Sensor	Adjustable reflective and transmissive sensors
Print Method	Thermal Transfer
Print Resolution	203 dpi
Memory	8 MB Flash, 16 MB SDRAM
Interface Options	USB, Serial, Ethernet, Parallel
Media Type	Roll-fed, die-cut, continuous, fan-fold, tags, ticket stock
Media Width	1.0 in (25.4 mm) to 4.65 in (118 mm)
Media Thickness	0.0025 in (0.0635 mm) to 0.010 in (0.254 mm)
Media Roll Diameter	8 inches (203 mm) max
Ribbon Width	1 to 4.33 inches (25.4 to 110 mm)
Ribbon Length	1968 ft (600 m)
Ribbon Core	1 inch (25.4 mm)
Label Width Range	1.0 in (25.4 mm) to 4.65 in (118 mm)
Label Length Range	0.25 to 39 inches (6.35 to 991 mm)
