Section 8
DriveRack
™
• Repeat the previous procedure when you wish to call up another device in the system.
8.8.1 - Configuring RTA
LOCAL/NETWORK SELECTION - This parameter allows the user to select either a
LOCAL(1) or NETWORK(2) RTA. Local indicates that you are working within the 480R,
while the Network indicates that you are through a selected unit on the network system.
8.8.2 - MIDI Setup
The MIDI channel parameter selects which MIDI channel the 480R will communicate on.
Selections are; OFF, 1-16 or OMNI.
The SyEx ID parameter selects the SYSEX ID for the currently selected DriveRack™ unit.
Selections are Off, 1-127 or OMNI.
8.8.3 - MIDI Bulk Dumps
The 480R unit is capable of dumping MIDI information from unit to another via the MIDI con-
nectors. To send a MIDI bulk dump, use the following procedure.
• Use the PREV PG and NEXT PG buttons to move to page 3 of the utility menu.
• Use the PARAMETER 3 knob to execute a bulk dump.
8.8.4 - Network Modes
The 480R provides the user with the redundancy on/off feature. This feature allows the select-
ed master unit to retain all programming information of all units used in a DriveRack™ network.
This simply means that in the unfortunate event that one of the units goes out of service, a
replacement unit can be added into the network and the information from the previous unit
will be added via the master unit. For more information about Redundancy, please refer to sec-
tion 7.4. To enable this feature, use the following procedure.
• Use the PREV PG and NEXT PG buttons to move to page 4 of the utility menu.
8.8 480R Utility Menu
DriveRack™ User Manual
