DriveRack™ User Manual
46
Section 4
DriveRack
™
The output section 480, 481, 442 and 482 DriveRack™ units provide the user with the ability to
control output levels of the unit and adjust phase compensation of loudspeakers within the sig-
nal path. The output level control is located in the signal path before the compressor/limiters;
this means that the compressor/limiter directly affects the output level. The parameters for the
Phase Compensation effect are as follows and are user adjustable. Please refer to section A.9
of the Appendix for a complete output signal routing diagram.
Level/Shift On/Off
This parameter is used to turn the selected output level and shift parameters on or off. When
level/shift is off, level is set to 0dB and phase is 0
0
.
Level Inf, -9.5 to 20.0dB
This parameter is used to set the overall output level of the selected output.
Phase Off, 0 to -360
0
This parameter sets the amount of phase within the selected output path. The phase is refer-
enced to the upper frequency of the selected output crossover band. Pressing the PARAME-
TER 3 knob will invert the phase of the entire band, giving an additional 180 degrees of phase.
4.9 Output Routing
