Network Functions
®
64
SECTION 7
DriveRack
™
Backbone Connections
The network system of the DriveRack™ has been configured to allow the units within a multi-
ple unit network configuration communicate through a Back bone type connection. This allows
the units to transmit and receive information immediately through the line instead of the con-
ventional daisy chain system. The illustration below shows an example of the Back Bone net-
work system.
Typical DriveRack Network
Back Bone System
RS 485 In
RS 485 Thru
RS 485 In
RS 485 Thru
RS 485 In
RS 485 Thru
RS 485 In
RS 485 Thru
RS 485 In
RS 485 Thru
7.2 Network Connections (Applications)
