DriveRack™ User Manual
112
Appendix A
DriveRack
™
482 and 442 Toggle RS-232/MIDI.
Press and hold <ID UP> and <ID DOWN> at power-up until "232" appears in the 7-Seg Display.
Watch as the fourth digit in the display toggles from "1" to "0" or from "0" to "1".
If the final result is "1" the system is set up to communicate with RS-232.
If the final result is "0" the system is set up to communicate with MIDI.
Let go of the buttons and normal resetting will continue.
The DriveRack™ units have the ability to update their operating systems (OS) with the latest version available via the
Internet. In order to perform a flash download your PC must be able to receive/transmit information through the RS 232
connector. The Flash download procedure is as follows:
1. Connect the RS 232 output from your PC to the RS 232 port of the DriveRack™.
2. Access the World Wide Web.
3. Go to www.dbxpro.com to access the latest OS version.
4. Download the latest OS version and all attached software.
5. Follow the detailed instructions from the website.
Start Flash Download Session (Front Panel 480 and 480R)
• Press and hold the PREV PAGE button on power-up until the following message appears:
"WAITING FOR FLASH DOWNLOAD"
At this point, follow the flash download instructions to perform a flash download.
Start Flash Download Session (Front Panel 481, 442 and 482)
Press and hold the PROGRAM UP and ID DOWN buttons on power-up until the following message appears
"FLSH"
• At this point follow the flash download instructions to perform a flash download.
480, 481 and 482
U1) 4 Way w/S+H EQ F21) 4 Way w/S+H EQ
U2) LCR w/Ext Sends F22) LCR w/Ext Sends
U3) 2 Way Monitors F23) 2 Way Monitors
U4) 4-Way w/BP Subs F24) 4-Way w/BP Subs
U5) 3-Way w/Mixer F25) 3-Way w/Mixer
U6) 4-Way Template F26) 4-Way Template
U7) 4-Way FOH w/RTA F27) 4-Way FOH w/RTA
U8) 4-Way w/Mono Sub F28) 4-Way w/Mono Sub
U9) LCR Template F29) LCR Template
U10) 3X7 LCR w/Rear F30) 3X7 LCR w/Rear
U11) LCR w/RTA F31) LCR w/RTA
U12) 3-Way Template F32) 3-Way Template
U13) 3-Way w/Delay F33) 3-Way w/Delay
U14) 3-Way FOH w/RTA F34) 3-Way FOH w/RTA
U15) 3-Way + 2-Way F35) 3-Way + 2-Way
U16) 2-Way Template F36) 2-Way Template
U17) 2-Way Monitors F37) 2-Way Monitors
U18) Dual 2-Way F38) Dual 2-Way
U19) Conf/Ballroom F39) Conf/Ballroom
U20) 4 Insert EQs F40) 4 Insert EQs
A.5 Program List
A.4 Flash Downloads
442
U1) 4 Insert EQs F1) 4 Insert EQs
U2) LCR w/ Aux Send F2) LCR w/ Aux Send
U3) Zones w/ PEQ F3) Zones w/ PEQ
U4) Dual EQ and RTA F4) Dual EQ and RTA
U5) Insert S&H EQs F5) Insert S&H EQs
U6) Insert Lnkd SH F6) Insert Lnkd SH
U7) LCR w/ PEQ RTA F7) LCR w/ PEQ RTA
U8) Mixed PEQ Zones F8) Mixed PEQ Zones
U9) LCR + Sub F9) LCR + Sub
U10) 2 Mono Zones F10) 2 Mono Zones
U11) Insert PEQs F11) Insert PEQs
U12) Insert S&H EQs F12) Insert S&H EQs
U13) 4 Zones w/ GEQ F13) 4 Zones w/ GEQ
U14) LCR PEQs F14) LCR PEQs
U15)
Mixed GEQ Zones F15) Mixed GEQ Zones
U16) Dual St PEQs F16) Dual St PEQs
U17) LCR w/ SH EQ F17) LCR w/ SH EQ
U18) Dual St EQs F18) Dual St EQs
U19) 4 Zones w/ EQ F19) 4 Zones w/ EQ
U20) LCR w/ RTA F20) LCR w/ RTA
