V0215, 10.16
To change the height dimension of the tool.
Auto Finish
Finishing the tool outline to the top of the tool automatically.
Reset Drawing
To reset the programmed drawing of the tool till the basic, initial shape, when creating a new
die.
Reload Drawing
To reload the programmed drawing of the tool till the basic, initial shape, when changing an
existing die.
Properties
To change the specific properties of the line or angle, add or remove a radius, change the
length, etc. It is e.g. possible to add a radius in the outline of the tool.
Tool Properties
To change the generic tool data and description.
Description
A name or description of this tool. The maximum length is 25 characters. This
description has already been entered in the beginning defining the tool, but can be
edited in this field. The description is listed in the tool overview of the library.
Resistance
Maximum allowable force on the tool.
