Dell OptiPlex 755 - Page 250

250 Drives
7 Disconnect the data and power cables from the drive connectors.
8 Remove the four screws that secure the drive rails to the existing hard drive, and attach the drive rails
to the replacement hard drive.
1 hard drive
2 drive rails (2)
3 data cable connector
4 power cable connector
2
1
3
4
