NOTICE: Serial ATA data and power connectors are keyed for correct insertion; that is, a notch or a missing pin on
one connector matches a tab or a filled-in hole on the other connector. When connecting cables to a drive, ensure
that the connectors are oriented properly before you attach the cables to the drive.
9
Attach the data and power cables to the hard drive connectors, ensuring that the connectors are
properly oriented before connecting them.
10
Slide the hard drive into the hard drive bracket.
1 drive
2 drive rails (2)
3 screws (4)
1
3
2
