Dell OptiPlex Gn - Front Bezel; Figure 6-3. Front-Bezel Removal

6-4
Dell OptiPlex Gn and Gn+ Systems Service Manual
F
ront Bezel
Figure 6-3. Front-Bezel Removal
To remove the front bezel, follow these ste
p
s:
1. Press the tab release marked with the icon.
2. Tilt the bezel away from the chassis.
3. Disengage the two retaining hooks at the bottom of the bezel, and pull
the bezel away from the chassis.
tab release
retaining hooks (2)
