Dell OptiPlex Gn - Computer Cover; Figure 4-2. Computer Cover Removal; Figure 4-3. Padlock

4-4
Dell OptiPlex Gn and Gn+ Systems Service Manual
C
omputer Cover
Figure 4-2. Computer Cover Removal
To remove the computer cover, follow these steps:
1. Remove the padlock if one is installed.
Figure 4-3. Padlock
2. Press the two securing buttons until the cover is free to swing up.
.
3. Raise the back of the cover and pivot it toward the front of the
computer.
4. Lift the cover off the hooks at the front of the chassis.
Before you reinstall the cover, fold all cables out of the way so that they do not
interfere with the cover or with the proper airflow inside the computer.
securing
buttons (2)
front of computer
hooks (3)
padlock
